5V 9V 12V 500MA 1A 1.0A Ac/dc Adapter Power Adaptor for Router /set Top Box/ Pos Machine

Product Description
9V/1A  AC DC Adapter 12W Wall Charger Wall Adapter
Input Voltage: 100~240Vac(Range:90~264Vac)
Input Current: 0.4A max
Frequency: 50/60Hz(Frequency range:47~63Hz)
Output voltage: 9V
Output current: 1A
Ripple & Noise: 120mV max
Power consumption at no load: 0.075W max
Conversion efficiency: >78.7%
Voltage regulation/Load regulation: ±2%/±5%
CC/CV
Hi-pot test: 3000 VAC/1min/5mA
Leakage current: 0.25mA max @240 VAC
With Over-current, Over-voltage, Over-temperature, Short-circuit protection function
Operating temperature: 0~45℃
Safety standards: UL1310 EN62368 UL62368 EN61558 GB8898
EMC standards: EN55032 class B FCC Part 15 class B EN55024/A1:2001 EN61000
Availability:
Quantity:
Inquire Add to Basket

  • HDS1201A

  • HUNDA

Product Description
9V/1A  AC DC Adapter 12W Wall Charger Wall Adapter
Input Voltage: 100~240Vac(Range:90~264Vac)
Input Current: 0.4A max
Frequency: 50/60Hz(Frequency range:47~63Hz)
Output voltage: 9V
Output current: 1A
Ripple & Noise: 120mV max
Power consumption at no load: 0.075W max
Conversion efficiency: >78.7%
Voltage regulation/Load regulation: ±2%/±5%
CC/CV
Hi-pot test: 3000 VAC/1min/5mA
Leakage current: 0.25mA max @240 VAC
With Over-current, Over-voltage, Over-temperature, Short-circuit protection function
Operating temperature: 0~45℃
Safety standards: UL1310 EN62368 UL62368 EN61558 GB8898
EMC standards: EN55032 class B FCC Part 15 class B EN55024/A1:2001 EN61000
