Switching Power Supply 5Volt 1.2Amp 5V 1.2A A 6Watt US ,EU,IN,AU,KR Plug Wall-mount Power Adapter

Product Description
6W 5W 5V 1A 12V 0.5A Power Adapter 5Watt Output Switching Power Supply

Input Voltage: 100~240Vac(Range:90~264Vac)
Input Current: 0.2A max
Frequency: 50/60Hz(Frequency range:47~63Hz)
Output voltage: 5V
Output current: 1.2A
Ripple & Noise: 120mV max
Power consumption at no load: 0.075W max
Conversion efficiency: >73.6%
Voltage regulation/Load regulation: ±2%/±5%
CC/CV
Hi-pot test: 3000 VAC/1min/5mA
Leakage current: 0.25mA max @240 VAC
With Over-current, Over-voltage, Over-temperature, Short-circuit protection function
Operating temperature: 0~45℃
Safety standards: EN61558 GB4706 IEC6238 UI6238 EN60950 GB4943
EMC standards: EN55032 FCC Part 15 class B EN61000 GB17615
Availability:
Quantity:
Inquire Add to Basket

  • HDS0601A

  • HUNDA

Product Description

6W 5W 5V 1A 12V 0.5A Power Adapter 5Watt Output Switching Power Supply

Input Voltage: 100~240Vac(Range:90~264Vac)
Input Current: 0.2A max
Frequency: 50/60Hz(Frequency range:47~63Hz)
Output voltage: 5V
Output current: 1.2A
Ripple & Noise: 120mV max
Power consumption at no load: 0.075W max
Conversion efficiency: >73.6%
Voltage regulation/Load regulation: ±2%/±5%
CC/CV
Hi-pot test: 3000 VAC/1min/5mA
Leakage current: 0.25mA max @240 VAC
With Over-current, Over-voltage, Over-temperature, Short-circuit protection function
Operating temperature: 0~45℃
Safety standards: EN61558 GB4706 IEC6238 UI6238 EN60950 GB4943
EMC standards: EN55032 FCC Part 15 class B  EN61000 GB17615
